Product Summary

The QM1000HA-24B is a transistor module which is designed for high power switching use.

Parametrics

QM1000HA-24B absolute maximum ratings: (1)Collector-emitter voltage: 1200 V; (2)Collector-emitter voltage: 1200 V; (3)Collector-base voltage: 1200 V; (4)Emitter-base voltage: 7 V; (5)Collector current: 1000 A; (6)Collector dissipation: 7000 W; (7)Base current: 50 A; (8)Junction temperature: -40 to +150℃; (9)Storage temperature: -40 to +125℃.

Features

QM1000HA-24B features: (1)IC Collector current: 1000A; (2)VCEX Collector-emitter voltage: 1200V; (3)hFE DC current gain: 750; (4)Insulated Type; (5)UL Recognized Yellow Card No. E80276 (N), File No. E80271.
